Establish a precise and repeatable reference point for your RockLock™ quick-change workholding system with 5th Axis Alignment Pallets.
Designed to help align the RockLock™ base with the CNC machine, these precision-machined pallets provide reliable reference surfaces for probing or indicating. Once the datum has been established, compatible fixtures and top tooling can be positioned consistently for faster and more efficient setups.
The 52mm Master Gauging Pallet is an essential setup tool for the RockLock™ 52mm quick-change system.
Hardened and precision-machined reference surfaces help users accurately align the RockLock™ baseplate with the CNC machine. Its compact design is suitable for 52mm RockLock™ bases and smaller workholding configurations.
Model: RL52-MP
The 96mm Master Gauging Pallet provides accurate reference surfaces for setting up and aligning the RockLock™ 96mm quick-change system.
Simply position the RockLock™ baseplate on the machine, install the master gauging pallet and use a probe or dial indicator to establish an accurate and repeatable machine datum.
Model: RL96-MP
Learn how the Master Alignment Pallet helps establish a known datum for RockLock™ workholding setups on 3-axis, 4-axis and 5-axis CNC machines.
The system is designed to reduce repeated indicating and help maintain consistent work offsets across compatible fixtures, pallets and machines.
