APPLITEC Cutting Tools

GENERAL CATALOGUE 2025-27 – APPLITEC Cutting Tools

APPLITEC Cutting Tools

TOP-Line

  • Coding guide
  • Infos and advantages
  • Grades
  • Standard machining data
  • PCD grades
  • PCD standard machining data
  • 710 / 720 – For cam-driven machines
  • 730 / 740
    – Main series
    – Small type
  • 750 / 760
    – Main series
    – Large type
  • 770 / 780
    High capacity parting off
  • 7050 / 7060
    High capacity parting
  • W750 / W760
    Tools with wide blank inserts for profiling
  • Specific toolholders
  • Spare parts

Details/Data Download

Category: Tag: Brand:

Infos and advantages

  • Applitec clamping system with shifted teeth
  • Standard clamping system (A)
  • Clamping system type B*
  • The insert can be changed in the machine without removing the toolholder

Grades

μK20

TiAlN

  • Best universal grade
  • First choice for steel, stainless steel, and titanium alloys machining
  • Very good heat resistance

TiAlX

  • Very wear-resistant and high-temperature resistant grade. Recommended for following material : Inox 304, 316L, 317L, 904, Phynox

• alloy steel containing: Chrome-nickel, Vanadium, Molybdenum, …

TiN

  • Grade for the machining of low resistance materials, which causes edge build-up
  • Very low friction ratio
  • Not suitable for titanium machining

ST

  • Wear and temperature-resistant grade. Recommended for the following materials: Inox, titanium alloys, nickel-based alloys, chrome-cobalt, and materials harder than > 50 HRC

N

  • suitable for interrupted cuts and other unfavourable machining conditions

Grades - μK10 - μK20

μK10 – μK20

KCR

  • Specific grade for non-ferrous materials such as copper, brass, lead-free brass, bronze, and nickel silver
  • Reduces sticking. Alternative to DLC coatings for certain applications

KCRF

  • A specific grade for non-ferrous materials such as copper, brass, lead-free brass, bronze, and nickel silver
  • reduces sticking. Alternative to DLC coatings for certain applications

KST

  • Grade with excellent wear resistance and toughness properties. Recommended for the following materials: Inox, titanium alloys, nickel-based alloys, chrome-cobalt, and materials harder than > 50 HRC

KN

  • micro-grain grade, combining excellent wear resistance with good toughness.
  • Recommended for machining materials that do not require any coating, such as pure titanium.

Grades - μK10

μK10

HTA

  • Very wear-resistant grade
  • For light machining of steel, stainless steel, and titanium alloys under favourable machining conditions

HTAX

  • Very wear-resistant and high-temperature resistant grade, for light machining of small parts with low cutting feed. Recommended for the following material: Inox 304, 316L, 317L, 904, Phynox

HCR-TF

  • Specific grade for non-ferrous materials such as copper, brass, lead-free brass, bronze, and nickel silver.
    Reduces sticking. Alternative to DLC coatings for certain applications

HTiN

  • Grade for light machining of low resistance materials, which causes edge build-up
  • very low friction ratio
  • Not suitable for titanium machining

HAC

  • Grade non-ferrous materials
  • Very low fiction ratio
  • First choice for aluminium up to 5% Si, copper, and low alloyed titanium

HN

  • Wear-resistant micro-grain grade
  • Suitable for the machining of low-alloyed titanium
  • Not suitable for interrupted cut
