Turning

• ULTRAMINI
  – Grooving, boring, and profiling
  – D min. ≥ Ø 5.0 mm
• MINICUT
  – Grooving, boring, and profiling

  – MINICUT: D min. ≥ Ø 7.0 mm
  – TRICUT: D min. ≥ Ø 7.8 mm

• MF TOOLS
  – Multifunctional tool drilling and boring
  – Typ DT: D min. ≥ Ø 2.00 mm
  – Typ DT MAX: D min. ≥ Ø 7.85 mm

• SWISSLINE
  – Miniature external machining, two-cutting edges

  – b ≥ 0.5 mm

• STECHDREHWERKZEUGE
  – Grooving with one-, two-, or three-cutting edges

  – SYSTEM DED: S ≥ 0.5 mm
  – SYSTEM D-GROOVING: b ≥ 2.0 mm

• NUTSTOSSEN
  – Broaching keyways and internal profiles

  – B ≥ 2.0 mm
  – D min. ≥ Ø 6.0 mm
  – SW ≥ 1.0 mm

Milling

• FM-LINE
  – Solid carbide micro end mills
  – DS ≥ Ø 0.2 mm
• MIKROMILL
  – Groove milling by circular interpolation,

  groove milling and T-slot milling
  – MIKROMILL:
  D min. ≥ Ø 4.0 mm
  Gewinde- Ø ≥ 1.0 x 0,25 mm
  thread- Ø ≥ 1.0 x 0,25 mm
  – MIKROMILL XL:
  DS ≥ Ø 12.5 mm

• MIKROMILL XL – T – Nutenfräsen / T – slot milling
• MINIMILL
  – Groove milling by circular interpolation,

  groove and slot milling
  – MINIMILL: D min. ≥ Ø 7.0 mm
  – MINIMILL XL: DS = Ø 50 mm

• SYSTEM 500
  – Groove milling by circular interpolation,

  groove and slot milling
  – DS ≥ Ø 44 mm
  – D min. ≥ Ø 45 mm
  – b ≥ 1.41 mm

• ROTALINE
  – Precision boring

  – D min. ≥ Ø 0.4 mm

• AXALINE
  – Rotating grooving head

  for flexible system solutions
  – D min. ≥ Ø 5.0 mm

Drilling

• BM-LINE
  – Solid carbide micro drills

  with spiralized high-performance cooling
  – D ≥ Ø 0.8 mm
  – Bohrungstiefen ≤ 30 x D
  – Drilling depths ≤ 30 x
